RT32QV002A 3.2" TFT LCD module

3.2" TFT LCD module with 240x320 resolution for standard supply or customized display assemblies.

Format 3.2" TFT LCD module

Form Portrait rectangle

Resolution 240x320

Interface 8-bit MCU / SPI

Touch No

Compare catalog

Image unavailable

Core specification

Engineering snapshot.

Model: RT32QV002A
Screen size: 3.2"
Display form: Portrait rectangle
Resolution: 240x320
Display mode: Transmissive TFT
Interface: 8-bit MCU / SPI
Brightness: 420 cd/m²
Touch: No
Temperature: -20℃~70℃
Viewing direction: All o'clock
Outline dimension: 53.60(H)×76(W)×2.45(T)mm
Active area: 48.60(W) X64.80 (H)
Driver IC: ST7789V
Response time: 30ms
Contrast ratio: 1200
Backlight: 6LEDS
Pixel pitch: 240(RGB)×320
Pixel configuration: Rectangle
Display color: 262K color
Pin count: 24pins
Logic voltage: 2.5V~3.3V

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
