RT183001A

1.83" TFT LCD module with 240x284 resolution for standard supply or customized display assemblies.

Format 1.83" TFT LCD module

Form Portrait rectangle

Resolution 240x284

Interface SPI

Touch No

Compare catalog

RT183001A display module

Core specification

Engineering snapshot.

Model: RT183001A
Screen size: 1.83"
Display form: Portrait rectangle
Resolution: 240x284
Display mode: Transmissive TFT
Interface: SPI
Brightness: 400 cd/m²
Touch: No
Temperature: -10°C to 60°C operating; -20°C to 70°C storage
Viewing direction: All o'clock
Outline dimension: 31.62(H) × 39.13(V) × 1.86(T) mm
Active area: 29.52(H) × 34.93(V) mm
Driver IC: ST7789P3-G6
Response time: 30 ms
Contrast ratio: 1200
Backlight: 3LEDS
Pixel pitch: 240*284
Pixel configuration: Rectangle
Display color: 262K
Pin count: 15 pins
Logic voltage: 2.4–3.3V
Power: 210 mW

Product views

Front and back module views.

RT183001A Front view

RT183001A Back view

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
