RT20QV126A 2" TFT LCD module

Core specification

Engineering snapshot.

Model

RT20QV126A

Screen size

2"

Display form

Portrait rectangle

Resolution

240x360

Display mode

Transmissive TFT

Interface

RGB + SPI

Brightness

320 cd/㎡

Touch

No

Temperature

-20℃ ~ 70℃

Viewing direction

ALL o’clock

Outline dimension

36.02(H) × 51.60(W) × 2.0(T) mm

Active area

30.60(W) X40.80 (H)

Driver IC

ST7789V

Response time

30 ms

Contrast ratio

800

Backlight

3LEDS

Pixel pitch

240(RGB) × 320

Pixel configuration

Rectangle

Display color

262K

Pin count

20 pins

Logic voltage

2.5~3.0V
