1.6-2.0 inch

RT20QV227A

2" TFT LCD module with 240x320 resolution for standard supply or customized display assemblies.

Format 2" TFT LCD module

Form Portrait rectangle

Resolution 240x320

Interface MCU

Touch No

Compare catalog

RT20QV227A display module

Core specification

Engineering snapshot.

Model: RT20QV227A
Screen size: 2"
Display form: Portrait rectangle
Resolution: 240x320
Display mode: Transmissive TFT，262K color
Interface: MCU
Brightness: 500 cd/㎡
Touch: No
Temperature: -10℃ ~ 60℃
Viewing direction: ALL o’clock
Outline dimension: 36.05(H) × 51.80(V) × 2.45(T) mm
Active area: 30.60(W) × 40.80(H) mm
Driver IC: ST7789
Response time: 30ms
Contrast ratio: 800
Backlight: LED
Pixel pitch: 240(RGB) × 320
Display color: 262K
Pin count: 22 pins
Logic voltage: 2.5~3.3V
Power: 210mWTBD

Product views

Front and back module views.

RT20QV227A Front view

RT20QV227A Back view

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
