RT40HD008A

4" TFT LCD module with 720x720 resolution for standard supply or customized display assemblies.

Format 4" TFT LCD module

Form Round

Resolution 720x720

Interface MIPI 2L

Touch No

Compare catalog

RT40HD008A display module

Core specification

Engineering snapshot.

Model: RT40HD008A
Screen size: 4"
Display form: Round
Resolution: 720x720
Display mode: Transmissive TFT
Interface: MIPI 2L
Brightness: 320cd/㎡
Touch: No
Temperature: -20℃~70℃
Viewing direction: All o'clock
Outline dimension: 57.14(H)×96.85(V)×2.05(T)mm
Active area: 51.84(H)×86.40(V)mm
Driver IC: ST7701S
Response time: 35ms
Contrast ratio: 800
Backlight: 8LEDs
Pixel pitch: 480(RGB)×800
Pixel configuration: Rectangle
Display color: 262K color
Pin count: 18pins
Logic voltage: 2.5V~3.3V
Power: 560mW

Product views

Front and back module views.

RT40HD008A Front view

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
