3.6-5.0 inch

RT40WV088A

4.3" TFT LCD module with 480x800 resolution for standard supply or customized display assemblies.

Format 4.3" TFT LCD module

Form Wide rectangle

Resolution 480x800

Interface MIPI 2L

Compare catalog

Image unavailable

Core specification

Engineering snapshot.

Model: RT40WV088A
Screen size: 4.3"
Display form: Wide rectangle
Resolution: 480x800
Display mode: Transmissive TFT
Interface: MIPI 2L
Brightness: 320cd/㎡
Temperature: -20℃~70℃
Viewing direction: All o'clock
Outline dimension: 57.14(H)×96.85(V)×2.05(T)mm
Active area: 51.84(H)×86.40(V)mm
Driver IC: ST7701S
Response time: 35ms
Contrast ratio: 800
Backlight: 8LEDs
Pixel pitch: 480(RGB)×800
Pixel configuration: Rectangle
Display color: 262K color
Pin count: 18pins
Logic voltage: 2.5V~3.3V
Power: 560mW

Product views

Front and back module views.

RT40WV088A Back view

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
