3.6-5.0 inch

RT50HD020A

5" TFT LCD module with 720x1280 resolution for standard supply or customized display assemblies.

Format 5" TFT LCD module

Form Wide rectangle

Resolution 720x1280

Interface MIPI

Compare catalog

RT50HD020A display module

Core specification

Engineering snapshot.

Model: RT50HD020A
Screen size: 5"
Display form: Wide rectangle
Resolution: 720x1280
Display mode: Transmissive TFT
Interface: MIPI
Brightness: 260cd/㎡
Temperature: -20℃~70℃
Viewing direction: All o'clock
Outline dimension: 66.90(H)×120.00(V)×1.90(T)mm
Active area: 62.10(H)×110.40(V)mm
Driver IC: ILI9881C
Response time: 30ms
Contrast ratio: 800
Backlight: 12LEDS
Pixel pitch: 720(RGB)×1280
Pixel configuration: Rectangle
Display color: 262K color
Pin count: 24pins
Logic voltage: 2.5V~6.0V
Power: 840mW

Product views

Front and back module views.

RT50HD020A Front view

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
