RT13QV005D

1.3" TFT LCD module with 240x240 resolution for standard supply or customized display assemblies.

Format 1.3" TFT LCD module

Form Compact rectangle

Resolution 240x240

Interface MCU

Touch No

Compare catalog

Image unavailable

Core specification

Engineering snapshot.

Model: RT13QV005D
Screen size: 1.3"
Display form: Compact rectangle
Resolution: 240x240
Display mode: Transmissive TFT
Interface: MCU
Brightness: 400 cd/m²
Touch: No
Temperature: -20°C to 70°C
Viewing direction: All o'clock
Outline dimension: 26.16 (W) X29.22(H) X1.92(T)
Active area: 23.4(W) X23.4 (H)
Driver IC: ST7789V
Response time: 35 ms
Contrast ratio: High
Backlight: LED
Pixel pitch: 240*240
Pixel configuration: Square
Display color: 262K
Pin count: 24Pins
Logic voltage: 2.8V-3.1V

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
