2.8-3.5 inch

RT35HD017A

3.5" TFT LCD module with 640x480 resolution for standard supply or customized display assemblies.

Format 3.5" TFT LCD module

Form Landscape rectangle

Resolution 640x480

Interface RGB

Touch No

Compare catalog

Image unavailable

Core specification

Engineering snapshot.

Model: RT35HD017A
Screen size: 3.5"
Display form: Landscape rectangle
Resolution: 640x480
Display mode: Transmissive TFT
Interface: RGB
Brightness: 530cd/㎡
Touch: No
Temperature: -10℃~60℃
Viewing direction: ALL o’clock
Outline dimension: 76.74(H)×63.74(V)×3.28(T)mm
Active area: 70.08(H)×52.56(V)mm
Driver IC: NV3052C
Response time: 25 ms
Contrast ratio: 800
Backlight: 6LEDS
Pixel pitch: 640(RGB)×480
Pixel configuration: Rectangle
Display color: 262K color
Pin count: 54pins
Logic voltage: 2.5V~3.6V
Power: 420mW

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
