RT30XG001A

3" TFT LCD module with 1024x768 resolution for standard supply or customized display assemblies.

Format 3" TFT LCD module

Form Landscape rectangle

Resolution 1024x768

Interface MIPI

Compare catalog

Image unavailable

Core specification

Engineering snapshot.

Model: RT30XG001A
Screen size: 3"
Display form: Landscape rectangle
Resolution: 1024x768
Display mode: Transmissive TFT
Interface: MIPI
Brightness: 520cd/㎡
Temperature: -20℃~70℃
Viewing direction: All o'clock
Outline dimension: 68.50(H)×50.28(V)×2.0(T)mm
Active area: 60.21(H)×45.16(V)mm
Driver IC: EK79210AF
Response time: 35ms
Contrast ratio: 1500
Backlight: 6LEDS
Pixel pitch: 1024(RGB)×768
Pixel configuration: Rectangle
Display color: 16.7M color
Pin count: 30pins
Logic voltage: 2.5V~3.3V
Power: 700mW

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
