RTP18WV001A

1.8" TFT LCD touch module with 360x360 resolution for standard supply or customized display assemblies.

Format 1.8" TFT LCD touch module

Form Round

Resolution 360x360

Interface MIPI

Touch Yes

Compare catalog

Image unavailable

Core specification

Engineering snapshot.

Model: RTP18WV001A
Screen size: 1.8"
Display form: Round
Resolution: 360x360
Display mode: TFT LCD
Interface: MIPI
Brightness: 480 cd/m²
Touch: Yes
Temperature: -20℃ ~ 70℃
Viewing direction: IPS full viewing angle
Outline dimension: 58.68(H) × 58.68(V) × 3.11(T) mm
Active area: 45.68(H) × 45.68(V) mm
Driver IC: ST77916
Touch IC: CST816D
Response time: 25 ms
Contrast ratio: 1200
Backlight: LED
Pixel pitch: 360*360
Pixel configuration: Square
Display color: 262K
Pin count: 20 pins
Logic voltage: 2.5~3.3V
Power: 210 mW

Commercial notes

Sampling, customization, and production support.

Samples: 3-5 days when in stock; mass production: 3-5 weeksLead time

Sample order available; mass-production MOQ commonly around 1KMOQ

FPC, cover lens, backlight, touch panel, logo, and bonding optionsCustomization
